C-45 Carbon Plate

Get a Price/Quote

MOQ : 100 Kilograms

C-45 Carbon Plate Specification

Tensile Strength
570 - 700 MPa

Hardness
170 - 210 HB

Size
As per order/standard sizes available

Diameter
N/A for plate (applies to rod/bar only)

Corrosion Resistant
Moderate (requires surface protection for enhanced durability)

Coating Type
No coating / As per requirement - can be supplied with oil or anti-rust coating

Heat Resistance
Yes

Product Form
Flat Plate

Material Composition %
Carbon: 0.42-0.50%, Manganese: 0.50-0.80%, Silicon: 0.10-0.35%, Sulphur & Phosphorus: max 0.040%

Recyclable
Yes

Product Name
C-45 Carbon Plate

Steel Type
Carbon Steel

Steel Product Type
Steel Plates

Grade
C45

Thickness
6 mm to 200 mm (as required)

Shape
Rectangular

Steel Standard
IS 2062, EN 10083, DIN 17200, BS 970

Surface
Mill Finish, Smooth

Composition
Carbon, Manganese, Sulphur, Phosphorus, Silicon

Application
Automobile components, industrial machinery, dies and tool making, engineering structures, general engineering purposes.

Dimension (L*W*H)
Custom sizes available (standard: 2000mm x 1000mm or 2500mm x 1250mm), thickness range as specified.

Weight
Varies as per dimensions and thickness (approx. 7.85 kg/m2 per mm thickness).

Color
Metallic Grey

Material Grade
C-45

Finish Type
Hot Rolled

Usage
Industrial, Construction, Automotive, Engineering

Weldability
Fair (preheating recommended before welding due to high carbon content)

Flatness Tolerance
As per ISDIN standards

Delivery Condition
Hot rolled, annealed or normalized as required

Edge Condition
As rolled or edge trimmed

Elongation
14% (min in 50 mm)

Density
7.85 g/cm3 (approx.)

Yield Strength
330 MPa (min)

Machinability
Good machinability with standard tools

Surface Condition
Can be supplied pickled or oiled if required

C-45 Carbon Plate Trade Information

Minimum Order Quantity
100 Kilograms

Payment Terms
Cash in Advance (CID)

Supply Ability
10000 Kilograms Per Month

Delivery Time
5-7 Days

Main Domestic Market
All India

About C-45 Carbon Plate

Experience the unprecedented strength and superlative performance of the C-45 Carbon Plate-offered for a limited time, now customizable to your specifications. Manufactured from impeccable carbon steel, this plate boasts a yield strength of 330 MPa and elongation of 14%, ensuring reliability in demanding industrial and engineering environments. With good machinability, fair weldability (preheating recommended), and adherence to ISDIN standards in flatness and edge condition, the C-45 plate sets a new benchmark. Available in a wide range of thicknesses and supplied with mill finish and optional coatings, it's a recyclable, robust solution for various sectors.

Versatile Applications & Surface Excellence

The C-45 Carbon Plate is renowned for its smooth, mill-finished surface, available pickled or oiled as needed. This material is designed for rugged industrial use in construction, automotive manufacturing, engineering structures, and tool-making. Its remarkable machinability and moderate heat resistance suit plant operations that demand precision and resilience, supporting everything from dies to machinery components. Selected for superlative application life and reliability, it is the benchmark for professional usage and diverse plant environments.

Secure Payment & Swift Export Solutions

Our comprehensive logistics support ensures the C-45 Carbon Plate is securely packed, handled with care, and shipped globally. Flexible payment terms cater to your business needs, making transactions seamless. Your order-custom or standard-is handed over promptly to trusted carriers for timely delivery. Certifications such as IS 2062, EN 10083, and DIN 17200 guarantee product quality. Our main export markets include Europe, the Middle East, Asia, and North America, ensuring broad international reach.

FAQ's of C-45 Carbon Plate:

Q: How can I order the C-45 Carbon Plate in custom dimensions?

A: You can place an order for the C-45 Carbon Plate in custom lengths, widths, and thicknesses by specifying your required dimensions. Both standard and tailored sizes are available, and our sales team will assist you throughout the process.

Q: What are the recommended applications for the C-45 Carbon Plate?

A: The C-45 Carbon Plate is ideal for automotive components, industrial machinery, dies, tool making, engineering structures, and construction projects due to its superb mechanical properties and durability.

Q: How should I process the C-45 Carbon Plate for welding?

A: Due to its high carbon content, it is recommended to preheat the C-45 Carbon Plate before welding to prevent material stress and cracks. Consult your welding specialist for optimal preheating temperatures.

Q: Where is the C-45 Carbon Plate commonly shipped from?

A: Our C-45 Carbon Plates are manufactured and supplied from India, but we facilitate global shipping to ensure timely delivery to your location.

Q: What certifications and standards does the C-45 Carbon Plate meet?

A: The C-45 Carbon Plate complies with IS 2062, EN 10083, DIN 17200, and BS 970 steel standards, ensuring it meets international requirements for strength and quality.

Q: When can I expect my order to be handed over to logistics?

A: Once your payment is confirmed and manufacturing is complete, your order is promptly handed over to our logistics partners for swift global shipment.
